Clover Fountain For Large, Commercial Ponds

Clover Fountain For Large, Commercial Ponds

SKU: 12998

$5,299.00

Wire Chart
Select the correct voltage/power before purchasing!
?
For proper operation of a 115-volt motor, the distance from the main breaker to the fountain or aerator must not exceed 100 feet. If it does, please select a 230-volt motor.

Clover Fountain 2-hp, 230 volts

  • 2-hp, 230-volt, oil-free motor.
  • 130 gallons of water per minute.
  • Center stream is 60 feet high.
  • Side jets’ angled spray pattern extends 60 feet.
  • Electric power cord provided is 100 feet in length, 10-gauge submersible, with plug. Can be ordered in greater lengths.
  • Light kits can be added later.
  • Approved for use in saltwater.
  • Two 45-pound weights or concrete blocks required for anchoring (not included).
  • Two nylon ropes required for anchoring (not included).
  • Designed for 24-hour-per-day operation.
  • No maintenance required.
  • 56-inch minimum pond depth required.
  • Motor specs: 230 volts, 60 Hz, single phase, 10 amps, 1,500 watts.
  • 5-year motor warranty.
  • ARL tested and approved to be in compliance with the applicable requirements of UL and the National Electric Code as complete packages.

Clover Fountain 3-hp, 230 volts

  • 3-hp, 230-volt, oil-free motor.
  • 180 gallons of water per minute.
  • Center stream is 70 feet high.
  • Side jets’ angled spray pattern extends 80 feet.
  • Electric power cord provided is 100 feet in length, 10-gauge submersible, with plug. Can be ordered in greater lengths.
  • Light kits can be added later.
  • Approved for use in saltwater.
  • Two 55-pound weights or concrete blocks required for anchoring (not included).
  • Two nylon ropes required for anchoring (not included).
  • Designed for 24-hour-per-day operation.
  • No maintenance required.
  • 60-inch minimum pond depth required.
  • Motor specs: 230 volts, 60 Hz, single phase, 13.3 amps, 2,200 watts.
  • 5-year motor warranty.
  • ARL tested and approved to be in compliance with the applicable requirements of UL and the National Electric Code as complete packages.

FOUNTAIN MOTOR SPECS (PDF)

Clover Fountain 2-hp, 230 volts

UPC#

MPN# 12998

Clover Fountain 3-hp, 230 volts

UPC# 810094920340

MPN# 12999
