The Tremendous TwoTier Commercial Fountain from Vertex!

The TwoTier Floating Fountain features a wide, spreading spray pattern designed to create a bold centerpiece that beautifully enhances any lake setting. Its all-brass display head produces strong, floral-style side jets that arch gracefully upward and outward, creating a highly visible and eye-catching display both during the day and when illuminated at night.

Built for lasting performance, the TwoTier fountain is powered by a heavy-duty submersible turbine pump and a UL-listed control panel for reliable operation. Every component is fully waterproof and constructed from premium, corrosion-resistant materials — ensuring years of dependable service and high-performance operation.

Warranty: All Vertex fountains feature a 4-year warranty on pumps/motors, flotation components, and cables along with a 2-year warranty on submersible light fixtures (excluding bulbs), and a 1-year warranty on controls.

Returns: Unused Vertex fountains are eligible for returns within 30 days, minus a 25% restocking fee. Please contact us for details.

Proudly Made in the USA

The following configurations are “standard” but we also offer custom motor and power cord configurations of Vertex Fountains including single phase (230 V) or three phase motors (208 V, 230 V, 460 V) and virtually any length power cord! Just give us a call at 1-616-355-2451!

TwoTier Fountain 5 hp

  • 5 hp, 230 or 460 V, 60 Hz, water-cooled and lubricated motor
  • Single phase (230 V) or three phase (460 V)
  • Amps:
    • Single phase, 230 V: 28
    • Three phase, 460 V: 8.6
  • Spray pattern measures:
    • Center jet: 26 feet high
    • Second tier: 12 feet high, 30 feet wide
  • Electric power cord provided:
    • Single phase, 230 V: 100 feet in length, 10-gauge
    • Three phase, 460 V: 100 feet in length, 12-gauge
    Electric power cord can be ordered in greater lengths
  • Ideal for ponds over 2 acres
  • 4-foot minimum pond depth required

TwoTier Fountain 7.5 hp

  • 7.5 hp, 230 V, 60 Hz, single phase, water-cooled and lubricated motor
  • Amps:
    • Single phase, 230 V: 42
  • Spray pattern measures:
    • Center jet: 30 feet high
    • Second tier: 15 feet high, 35 feet wide
  • Electric power cord provided:
    • Single phase, 230 V: 100 feet in length, 8-gauge
    Electric power cord can be ordered in greater lengths
  • Ideal for ponds over 2 acres
  • 5-foot minimum pond depth required

TwoTier Fountain 10 hp

  • 10 hp, 230 or 460 V, 60 Hz, water-cooled and lubricated motor
  • Single phase (230 V) or three phase (460 V)
  • Amps:
    • Single phase, 230 V: 51
    • Three phase, 460 V: 15.8
  • Spray pattern measures:
    • Center jet: 35 feet high
    • Second tier: 17 feet high, 40 feet wide
  • Electric power cord provided:
    • Single phase, 230 V: 100 feet in length, 8-gauge
    • Three phase, 460 V: 100 feet in length, 12-gauge
    Electric power cord can be ordered in greater lengths
  • Ideal for ponds over 2 acres
  • 6-foot minimum pond depth required

TwoTier Fountain 15 hp

  • 15 hp, 230 V, 60 Hz, single phase, water-cooled and lubricated motor
  • Amps:
    • Single phase, 230 V: 72
  • Spray pattern measures:
    • Center jet: 40 feet high
    • Second tier: 20 feet high, 45 feet wide
  • Electric power cord provided: 100 feet in length, 6-gauge
    Electric power cord can be ordered in greater lengths
  • Ideal for ponds over 2 acres
  • 7-foot minimum pond depth required

Safety & Compliance: Vertex fountains must be removed from water prior to freezing conditions. Please see owner’s manual for complete installation instructions, warranty details, and maintenance guidelines.
