DA-20 Display Aerator for Medium, Residential Ponds

DA-20 Display Aerator for Medium, Residential Ponds

SKU: 14025.1

$2,369.00

Wire Chart
Enjoy Free Shipping on This Item! 🎉🚚
GET THE POWER REQUIREMENT CORRECT BEFORE YOU MAKE YOUR NEW PURCHASE!
?
If an outlet runs to the water area, dock, etc that is within 100ft of the main breaker, that is ok. But, if the total distance exceeds 100ft, 115v will not work properly.

Our Most Popular Display Aerator for Medium, Residential Ponds!

DA-20 1 hp

  • 1-hp, 115-volt or 230-volt motor
  • 500 gallons-per-minute flow rate
  • Default spray pattern measures 7 feet high, 25 feet wide.
  • Electric power cord provided is 70 feet long, 12-gauge submersible, with plug.
  • Electric power cord can be ordered in greater lengths.
  • Light kits can be added at purchase or later.
  • Approved for use in saltwater.
  • Two 30-pound weights or concrete blocks required for anchoring (not included).
  • Two nylon ropes required for anchoring (not included).
  • Designed for 24-hour-per-day operation.
  • No maintenance required
  • 36-inch minimum pond depth required.
  • Motor specs: 115 volts, 60 Hz, single-phase, 11.5 amps, .75 kw, 3450 rpm, 14.4 max amps
  • Motor specs: 230 volts, 60 Hz, single-phase, 8.2 amps, .75 kw, 3450 rpm, 1.4 sf, 10.4 max amps
  • 5-year motor warranty
  • Available in 3-phase version and also available in 50 Hz
  • Suitable for ponds 1/8 acre or larger
  • ARL tested and approved to be in compliance with the applicable requirements of UL and the National Electric Code as complete packages.

DA-20 1½ hp

  • 230-volt, 1½-hp, oil-free motor
  • 600 gallons-per-minute flow rate
  • Spray pattern measures 10 feet high, 25 feet wide.
  • Electric power cord provided is 100 feet long, 12-gauge submersible, with plug.
  • Electric power cord can also be ordered In greater lengths.
  • Light kits can be added at purchase or later.
  • Approved for saltwater
  • Two 40-pound weights or concrete blocks required for anchoring (not included).
  • Two nylon ropes required for anchoring (not included).
  • Designed for 24-hour-per-day operation.
  • No maintenance required
  • 38-inch minimum pond depth required.
  • Motor specs: 230 volts, 60 Hz, single-phase, 10.6 amps, 1780 watts
  • 5-year motor warranty
  • Available in 3-phase version
  • Available in 50 Hz
  • ARL tested and approved to be in compliance with the applicable requirements of UL and the National Electric Code as complete packages.

DA-20 1 hp, 115 volts

UPC# 810094920937

MPN# 14025.1

DA-20 1 hp, 230 volts

UPC# 810094920920

MPN# 14025

DA-20 1½ hp, 230 volts

UPC# 810094920883

MPN# 14022
