North Star Fountain Aerator for Small, Residential Ponds

North Star Fountain Aerator for Small, Residential Ponds

SKU: 14018

$1,809.00

Wire Chart
Select the correct voltage/power before purchasing!
?
For proper operation of a 115-volt motor, the distance from the main breaker to the fountain or aerator must not exceed 100 feet. If it does, please select a 230-volt motor.

North Star ⅓ hp

  • ⅓ hp, 115 or 230 V, oil-free motor
  • 60 Hz, single-phase, 3,450 rpm (0.55 kW)
  • Current draw:
    • 115 V: 10.7 amps
    • 230 V: 6.8 amps
  • Also available in 3-phase and/or 50 Hz versions
  • 300 gallons-per-minute flow rate
  • Spray pattern measures 5 feet high, 12 feet wide
  • 5-year motor warranty
  • Easy installation
    • 115 V: 70 feet in length, 10-gauge, submersible, with plug
    • 230 V: 70 feet in length, 12-gauge, submersible
  • Electric power cord can be ordered in greater lengths
  • Approved for saltwater
  • Light kits can be added at purchase or later
  • Two 20-pound weights or concrete blocks required for anchoring (not included)
  • Two nylon ropes required for anchoring (not included)
  • Designed for 24-hour-per-day operation
  • No maintenance required
  • Ideal for ponds up to ¾ acre
  • 32-inch minimum pond depth required

North Star ½ hp

  • ½ hp, 115 or 230 V, oil-free motor
  • 60 Hz, single-phase, 3,450 rpm (0.55 kW)
  • Current draw:
    • 115 V: 10.7 amps
    • 230 V: 6.8 amps
  • Also available in 3-phase and/or 50 Hz versions
  • 400 gallons-per-minute flow rate
  • Spray pattern measures 6 feet high, 14 feet wide
  • 5-year motor warranty
  • Easy installation
  • Electric power cord provided (115 V): 70 feet in length, 12-gauge, submersible, with plug
  • Electric power cord can be ordered in greater lengths
  • Approved for saltwater
  • Light kits can be added at purchase or later
  • Two 25-pound weights or concrete blocks required for anchoring (not included)
  • Two nylon ropes required for anchoring (not included)
  • Designed for 24-hour-per-day operation
  • No maintenance required
  • Ideal for ponds greater than ⅛ acre
  • 32-inch minimum pond depth required

North Star ¾ hp

  • ¾ hp, 115 or 230 V, oil-free motor
  • 60 Hz, single-phase, 3,450 rpm (0.55 kW)
  • Current draw:
    • 115 V: 10.7 amps
    • 230 V: 6.8 amps
  • Also available in 3-phase and/or 50 Hz versions
  • 450 gallons-per-minute flow rate
  • Spray pattern measures 8 feet high, 16 feet wide
  • 5-year motor warranty
  • Easy installation
  • Electric power cord provided (115 V): 70 feet in length, 12-gauge, submersible, with plug
  • Electric power cord can be ordered in greater lengths
  • Approved for saltwater
  • Light kits can be added at purchase or later
  • Two 25-pound weights or concrete blocks required for anchoring (not included)
  • Two nylon ropes required for anchoring (not included)
  • Designed for 24-hour-per-day operation
  • No maintenance required
  • Ideal for ponds greater than ⅛ acre
  • 34-inch minimum pond depth required

Safety & Compliance: A GFCI (Ground Fault Circuit Interrupter) is required. Always disconnect power when swimmers are present. Each North Star aerator is ARL-tested and fully compliant with UL standards and the National Electric Code when installed as a complete package.

North Star ⅓ hp, 115 V

UPC#

MPN# 14018

North Star ½ hp, 115 V

UPC# 810094920876

MPN# 14020.1

North Star ¾ hp, 115 V

UPC# 810094921149

MPN# 14135

North Star ⅓ hp, 230 V

UPC#

MPN# 14019

North Star ½ hp, 230 V

UPC# 810094921835

MPN# 14021.1

North Star ¾ hp, 230 V

UPC# 810094921156

MPN# 14135.1
